Home Stretch Membrane is designed and recommended for typical below-grade waterproofing over a variety of approved substrates, but the sheet membrane waterproofing system can be continued on above-grade walls on a very limited basis.

The approval criteria for continuing the Home Stretch Membrane sheet waterproofing system from below grade to top of above-grade wall(s) include the following:

1. The approved above-grade wall substrate shall be only Insulated Concrete Forms (ICF), not concrete or traditional framing with sheathing.
2. The 30-day UV exposure limit on Home Stretch Membrane must be strictly followed. For an extended UV exposure limit up to 24 months, the UV2-40 (Formerly Aluma Flash Plus) sheet air barrier system is available for your review and consideration.

The Polyguard below-grade waterproofing systems require a vertical concrete substrate (i.e. foundation wall) to have a maximum moisture content of 10%, and a horizontal concrete substrate (i.e. footer) to have a maximum moisture content of 5%.

This requirement is to ensure proper adhesion/bond, while also preventing the Polyguard Stretch Flex (fluid-applied) membrane from developing surface blisters due to sunlight heating the substrate wall and/or footer and cause latent moisture to move within the concrete.

We have two application options approved for stucco veneers:

1. Use conventional wire lath (reinforcing mesh) with the stucco veneer. Mechanically fasten the lath through the cured Polyguard Blue Barrier fluid-applied air barrier membrane, whether the 2300 Liquid Wrap or the 2400 Flash “N Wrap, and the substrate sheathing beneath. This will allow the reinforcing mesh to be self-supported. Maintain the air- and water-tight seal, thereby the air barrier performance, by applying and tooling a minimum 30 mils of Blue Barrier Gap Filler over each mesh fastener head penetrating through the cured Blue Barrier fluid-applied air barrier membrane. With the lath installed and self-supported, the stucco basecoat (and finish coat) must be completed within (12) months of the Blue Barrier fluid-applied air barrier membrane application.
2. Broadcast silica sand into the wet Blue Barrier fluid-applied air barrier membrane, whether the 2300 Liquid Wrap or the 2400 Flash ‘N Wrap membrane, to the point of refusal to accept anymore silica sand. Once the Blue Barrier fluid-applied membrane is cured, apply Lambert Corporation’s 932 Link, a water-based bonding agent, onto the Blue Barrier membrane. Also, add the 932 Link into the stucco basecoat using a 1:3 mixing ratio. Allow the stucco basecoat to cure a minimum two (2) days before applying the stucco finish coat.

How do you recommend I waterproof it with your products?

ICF wall construction will need to be waterproofed using the Poly Wall ‘Home Stretch Membrane for ICF’ sheet waterproofing system. Do not use the ‘Home Stretch Liquid’ waterproofing system because it will attack / eat the ICF wall substrate!

Would I need to prime all surfaces?

Yes, the Poly Wall ‘Home Stretch WB Liquid Adhesive’ is the primer accessory product safe for the ‘Home Stretch Membrane for ICF’ sheet waterproofing system. Prime all surfaces and membrane laps to ensure a proper adhesive bond to the ICF substrate surface. Do not use the ‘Polybond Clear Liquid Adhesive’ primer accessory product, which is reserved only for concrete substrate wall surfaces. A level of caution here, as the Polybond Clear Liquid Adhesive primer will attack/eat the ICF wall substrate!!

Would peel and stick work on horizontal surfaces?

No, do not apply Poly Wall sheet or fluid-applied waterproofing systems onto horizontal (floor) surfaces. They are designed for vertical (wall) applications only, and are not recommended for horizontal (floor) surfaces.

All Blue Barrier Products utilize our Silyl Terminated Polyether Technology (STPE). These are hybrid sealants that combine the benefits of silicone and polyurethane technologies. By combining these chemistries, we achieve the best features of both, resulting in highly effective sealants. These sealants are low in VOCs, moisture-cured, and have a UV exposure rating of up to 9 months. The main differences in the product lines are their viscosity and intended applications:

•  Blue Barrier Gap Filler (BB GF): This product has the highest viscosity and is the thickest. BB GF contains fillers that make it a durable and tough adhesive, suitable for filling substrate voids, bonding dissimilar material joints, and serving as a membrane lap and termination sealant.
• Blue Barrier Liquid Flash (BB LF): This product has medium viscosity and thickness, making BB LF trowelable in a gun and spread application. BB LF is commonly used for sealing window and door openings.
• Blue Barrier Liquid Wrap (BB LW): This product has the lowest viscosity and is the thinnest. BB LW can be applied with an airless sprayer or power roller, making it ideal for large-scale field applications and a superior alternative to traditional house wraps.
