TRM Sill

$58.63
TERM® Non-Chemical Termite Barrier – Sill Barrier Excludes Moisture and Termites
Prairie Sun & Timber: Foundations From The Ground Up - Episode 1

TRM Sill

TRM Sill is a "peel and stick" non-chemical termite barrier installed directly on concrete beneath the sill plate to block subterranean termite entry....
Size
6" x 66.7'
7" x 66.7'
8" x 66.7'
9" X 66.7'
10" x 66.7'
12" x 66.7
$58.63

Overview

TRM Sill is a "peel and stick" non-chemical termite barrier installed directly on concrete beneath the sill plate to block subterranean termite entry.

Key Features of TRM Sill
  • Type: "Peel and stick" supplemental non-chemical termite barrier.
  • Installation: Applied directly on the concrete underneath the sill plate.
  • Function:
    • Blocks entry of subterranean termites at a common entry point.
    • Acts as a barrier to moisture and energy leaks.
    • Can block entry at the exposed underside of the sill plate.
  • Sizes: Available in 66.7-foot rolls with widths of 6", 7", 8", 9", 10", and 12".
  • Certification: It is the only waterproofing membrane that meets ICC AC 380 (ICC-ESR 3632) Acceptance Criteria.
  • Adhesion: Use of a primer, such as Polyguard's 650 WB Liquid Adhesive, is recommended for superior adhesion.
TRM Sill - Data Sheet
TRM Sill - Product Overview Sheet
TRM Flashing/TRM UV2-40/TRM Sill - Guide Spec
TRM Sill - HPD
TRM Sill - SDS

Product Resources

TRM Flashing/TRM UV2-40/TRM Sill - Detail Set - (FT1a-7b)
  • TERM
  • Detail(s)
TRM Flashing/Sill Flashing - Detail - Exterior Perimeter (FT1a)
  • TERM
  • Detail(s)
TRM Flashing/Sill Flashing - Detail - Exterior Perimeter at Balcony or Patio (FT1b)
  • TERM
  • Detail(s)
TRM Flashing/Sill Flashing - Detail - Water Termite Barrier Membrane Interior Framing (FT2)
  • TERM
  • Detail(s)
TRM Flashing - Detail - Installation Sequence (FT3)
  • TERM
  • Detail(s)
TRM Flashing over TRM Sill Flashing - Detail - In Cavity Wall (FT4a)
  • TERM
  • Detail(s)
TRM Flashing - Detail - In Cavity Wall (FT4b)
  • TERM
  • Detail(s)
TRM Flashing - Detail - Window Flashing (FT5)
  • TERM
  • Detail(s)
TRM Sill Flashing - Detail - Precast Wall w Steel Frame (FT6)
  • TERM
  • Detail(s)
TRM Sill Flashing - Detail - Stem Wall Transition to ICF Wall (FT7a)
  • TERM
  • Detail(s)
TRM Sill Flashing - Detail - Stem Wall Transition to ICF Wall (FT7b)
  • TERM
  • Detail(s)
TRM Sill - Data Sheet
  • TERM
  • Product Data Sheet (PDS)
TRM Sill - HPD
  • TERM
  • Health Product Declaration (HPD)
TRM Sill - SDS
  • TERM
  • Safety Data Sheet (SDS)
TRM Flashing/TRM UV2-40/TRM Sill - Guide Spec
  • TERM
  • Guide Spec
TRM Sill - Product Overview Sheet
  • TERM
  • Product Overview Sheet

Features & Benefits

Each roll of TRM Sill protects 66.7' of sill plate
4-mil high density polyethylene film bonded to 64 mils of sealant = 68 mils thick
Roll widths are 6”, 7”, 8", 9", 10", & 12"
Formulated from polymer asphalt which has been upgraded to incorporate a nonchemical termite and insect barrier
The sealant is laminated to a high strength and puncture resistant polyethylene backing
The only physical termite barrier with over 2 decades of testing and an evaluation report by the ICC (Internation Code Council) AC 380 ESR 3632
30 day UV exposure
ICF (Insulated Concrete Forms) Compatible
